Self-dumping
HF-WOLF-4D
Four-Wheel Self-Dumping Sweeper
A four-wheel high-output sweeper with hydraulic self-dumping for demanding municipal and industrial routes.
Product images may show optional equipment.Hydraulic self-dumping
15,000-20,000 m²/h
Up to 2,300 mm sweeping
Application fit
Purpose-built performance.
- Hydraulic dumping reduces manual waste handling at the end of each route
- Four-wheel chassis and enclosed cab support stable outdoor operation
- Dual-fan dust control and optional washing modules suit heavy-debris projects
Configuration review
We confirm the route, debris, duty cycle, climate, charger, local electrical conditions and required options before the final quotation.
Operating video
Request footage for HF-WOLF-4D
Ask our team for current working videos and configuration details for this platform.
Request model footageTechnical data
Key specifications.
Values describe the current typical configuration. Final specifications are confirmed for each order and destination market.
Request a configuration sheet →| Sweeping width | 1,500-2,300 mm |
|---|---|
| Main brush | 800 × 420 mm |
| Efficiency | 15,000-20,000 m²/h |
| Battery | 48 V / 153-203 Ah |
| Hopper | 200 L self-dumping |
| Water capacity | Approx. 200 L |
| Drive / roller motor | 2,200 W / 1,200 W |
| Side brushes | 2 × 700 mm front + 2 × 600 mm rear |
| Filtration area | 10 m² |
| Dimensions / weight | 3,300 × 2,300 × 2,500 mm / 1,200 kg |
