All-round heavy-duty
HF-AR240
Four-Wheel All-Round Sweeper
A heavy-duty four-wheel platform with adjustable brush reach, twin filtration and a 240 L hopper.
Product images may show optional equipment.1,500-2,300 mm sweeping
15,000-20,000 m²/h
240 L hopper
Application fit
Purpose-built performance.
- Four-wheel chassis supports stable municipal and industrial operation
- Twin fans, twin filters and twin dust-shaking systems strengthen dust control
- Pressure washing, fog cannon and directional spray packages are available
Configuration review
We confirm the route, debris, duty cycle, climate, charger, local electrical conditions and required options before the final quotation.
Operating video
Request footage for HF-AR240
Ask our team for current working videos and configuration details for this platform.
Request model footageTechnical data
Key specifications.
Values describe the current typical configuration. Final specifications are confirmed for each order and destination market.
Request a configuration sheet →| Sweeping width | 1,500-2,300 mm |
|---|---|
| Main brush | 800 mm |
| Efficiency | 15,000-20,000 m²/h |
| Battery | 48 V / 153-203 Ah lithium |
| Hopper | 240 L |
| Water capacity | Approx. 200 L; larger dual-tank option |
| Drive / roller motor | 2,200 W / 1,000 W |
| Side brushes | 2 × 700 mm front + 2 × 600 mm rear |
| Filtration area | 20 m² |
| Dimensions / weight | 3,300 × 2,300 × 2,600 mm / 1,500 kg |
